I4C IMPACT CRUSHER
The I4C Crusher is the latest entry into McCloskey’s powerful impact crusher line.
The I4C is in a class of its own, bringing the productivity of an 1125mm (44.3″) impactor to a compact footprint for maximum power and maneuverability.
The I4C is in a class of its own, bringing the productivity of an 1125mm (44.3″) impactor to a compact footprint for maximum power and maneuverability.
The crusher’s design has ease of access in mind, with an excellent layout for operation, maintenance and service. Advanced clutch technology delivers reduced fuel consumption, and less maintenance while increasing safety and productivity.
With its simplified controls and efficient hydraulics, the I4C heavy duty track mounted crusher is sure to make an impact across a variety of materials and applications.
With its simplified controls and efficient hydraulics, the I4C heavy duty track mounted crusher is sure to make an impact across a variety of materials and applications.
Features
1050mm (41.3") diameter x 1125mm (44.3") wide Impactor
375Hp (280kW) engine
Crawler Tracks
Integrated hydraulic folding stockpiling conveyors
I-beam plate fabricated chassis construction
Open chassis design for ease of maintenance
Specifications
| Engine | 375Hp (280kW) |
| Transport Height |
10' 6" (3.2m) |
| Transport Length |
36' 7" (11.16m) |
| Transport Width |
8'8" (2.65m) |
| Impact Rotor |
41.3" diameter x 44.3" wide |
| Stockpile Height (Side Conveyor) |
9' 1" (2.76m) |
