J50 JAW CRUSHER

With 1270mm (50”) x 735mm (29”) single toggle jaw (the widest jaw in its class), the J50 places McCloskey International at the fore of portable crushing machinery.

Maximum productivity is delivered through the enhancements to the jaw box including heavier flywheels and optimization for all crushing applications. The J50’s jaw speed leads to better reduction and material being processed faster through the crushing chamber.

McCloskey International has a proven reputation for designing quality, best-in-class equipment and the J50 Crusher brings even more power and productivity together in one machine. With its class-leading throughput and capacity and the largest stockpile height in its category the J50 crusher continues to push the boundaries of industry performance.

Features

True 1270mm (50") x 735mm (29") jaw
Hydraulic close side setting (CSS) adjust
Engine hydraulic system provides reverse jaw motion
Folding Hardox® hopper
1200mm (48") main conveyor
User friendly control panel
Optional pre-screen

Specifications

Engine* 261kW (350Hp)
Feed Opening**
1270mm (50") x 735mm (29")
Crusher Speed
280 rpm
Grizzly Feeder
1164 (45.8") x 4450mm (175")
Hopper Volume
6.8m³ (8.9yd³)
Stockpile Height Main Conveyor
4250mm (13'-11")
Stockpile Height Side Conveyor
2580mm (8'-6")
*Engine options vary. Consult your local dealer. **Peak to trough.
