R105 SCREENER
The McCloskey R105 High Energy Durable Screener provides the best solution for operators who don’t require the capacity of the larger screener models. Built around McCloskey International’s highly productive High Energy Screenbox, the R105 screener has all the class leading features of the R-Range, such as high quality components, durability and reliability and is also available in dual power.
Offering the highest stockpile and largest screening area in its class, while meeting the European transport regulation width, the R105 represents the most cost effective productivity and quality on the market in a versatile and mobile package.
Features
Dual Power available
Heavy duty high energy 2 bearing screenbox
Screen raises for easy access to bottom deck
Integrated hydraulic folding stockpiling conveyor with heavy duty belt as standard
Direct feed Hardox® hopper as standard
Large open engine bay
Travel out fixed walkways
Optimal 10 minute set up
Specifications
| Engine* | 98 kw (130 HP) |
| Screenbox Top Deck |
3.66m (12') x 1.370m (4'-6") |
| Screenbox Bottom Deck |
3.455m (11.4') x 1.370m (4'-6") |
| Feed Conveyor Belt Width |
1200mm (48") |
| Stockpile Height - Tail Conveyor |
3.45m (11'-4") |
| Stockpile Height - Fine Product Side Conveyor |
3.6m (11'-10") |
| Stockpile Height - Mid Product Side Conveyor |
3.63m (11'-11") |
