R230 SCREENER
The McCloskey R230 High Energy Durable Screener is one of the most robust, durable and powerful heavy-duty mobile screeners at work around the world today. Designed to provide uncompromising production levels to scalping operations, the R230 screener is capable of operating as a stand-alone plant producing finished product, or as a primary scalping component to the very largest of portable crushing spreads.
With the dual power R230, operational fuel efficiency is maximized while reducing costs, and is perfect where environmental, legislative, or noise constraints are present. McCloskey International’s powerful High Energy Screener delivers higher outputs and a high-quality screened product with maximum efficiency. The R230 is unequalled in its productivity and versatility.
Features
Dual Power available
Large loading area
Adjustable flow speed
6100mm (20') x 1830mm (6') 2 bearing screenbox
Direct feed Hardox® lined hopper as standard
Highest product capacity in its class
Low Profile Direct Load model available
10 minute set up time
Specifications
| Engine* | 168 kW (225 HP) |
| Screenbox Top Deck |
6.1m (20') x 1.83m (6') |
| Screenbox Bottom Deck |
5.49m (18') x 1.83m (6') |
| Feed Conveyor Belt Width |
1500mm (60') |
| Stockpile Height Tail Conveyor |
3.83m (12' - 6") |
| Stockpile Height Fine Product Side Conveyor |
4.10m (13'-5.3") |
| Stockpile Height Mid Product Side Conveyor |
3.66m (12') |
